Texsil Silica Fabrics

Texsil Silica Fabrics
Texsil silica fabrics are high temperature fabrics used in a wide range of insulation and protection applications such as welding curtains, welding blankets and welding pads. Texsil silica fabrics have a minimum silicon dioxide content of 96% and can be fabricated into many forms to withstand temperatures up to 1000°C. Texsil silica fabrics are available with our standard proprietary surface treatment for improved handling and fray resistance. Texsil silica fabrics are extensively used in the Power Generation, Refineries, Shipbuilding and Repair, Metal Processing, Petro-Chemical, Aerospace and Automotive industries.

Code

Product

Thickness
(mm)

Weight
(g/m2)

Temp

(℃)

WSF030TH

Texsil Silica Fabric

0.30

300

1000

WSF040TH

Texsil Silica Fabric

0.40

400

1000

WSF075TH

Texsil Silica Fabric

0.75

600

1000

WSF100TH

Texsil Silica Fabric

1.00

880

1000

WSF130TH

Texsil Silica Fabric

1.30

1100

1000

WSF140TH

Texsil Silica Fabric

1.40

1220

1000

WSF150TH

Texsil Silica Fabric

1.50

1350

1000

Available width: 914mm, 1000mm, 1200mm, 1300mm.

Available color: tan color and white color

Property: SiO2 >96%, LOI <10%, Linear Shrinkage <10%

Texsil Ultra Silica Fabrics
Texsil Ultra silica fabrics are improved with higher tensile strength and abrasion strength. it can be used for various coatings, including silicone, PU, PTFE, aluminized, graphite, vermiculite etc. for fire curtains, removable insulation blankets, car fire blankets, battery bag, heat shields, duct hoses,etc..  Texsil Ultra silica fabrics have a minimum silicon dioxide content of 96% and can be fabricated into many forms to withstand temperatures up to 1000°C. Texsil Ultra silica fabrics are extensively used in the Power Generation, Refineries, Shipbuilding and Repair, Metal Processing, Petro-Chemical, Aerospace and Automotive industries.

Code

Product

Thickness
(mm)

Weight
(g/m2)

Temp

(℃)

WSF030WHS

Texsil Ultra Silica Fabric

0.30

300

1000

WSF040WHS

Texsil Ultra Silica Fabric

0.40

400

1000

WSF060WHS

Texsil Ultra Silica Fabric

0.60

600

1000

WSF080 WHS

Texsil Ultra Silica Fabric

0.80

900

1000

WSF100 WHS

Texsil Ultra Silica Fabric

1.00

1120

1000

WSF120 WHS

Texsil Ultra Silica Fabric

1.20

1350

1000

Available width 914mm, 1000mm, 1200mm, 1500mm

Available color: white color

Property: SiO2 >96% (>97%), LOI <10%, Linear Shrinkage <10%

Texsil Pro Silica Fabrics
Texsil Pro silica fabrics are pre-shrunk satin weave silica textiles have the same thermal performance characteristics as our standard Texsil Ultra silica fabrics in addition to low residual shrinkage. Texsil Pro silica fabrics are used in industrial and aerospace applications that require minimum shrinkage at high temperatures. The areal shrinkage can be as low as 2% at 1000°C. Potential applications include: backing for quartz heaters, tray liners for thermal processing of parts, manufacturing of aerospace insulation parts, and mold release in metal forging. Texsil Pro silica fabrics are extensively used in the Power Generation, Aerospace, Electronics, Chemical Processing and Metal Processing industries.

Code

Product

Thickness
(mm)

Weight
(g/m2)

Temp

(℃)

WSF026WHP

Texsil Pro Silica Fabric

0.26

240

1000

WSF040WHP

Texsil Pro Silica Fabric

0.40

400

1000

WSF060WHP

Texsil Pro Silica Fabric

0.60

600

1000

WSF075WHP

Texsil Pro Silica Fabric

0.75

675

1000

WSF110WHP

Texsil Pro Silica Fabric

1.10

1120

1000

Available width 820mm, 860mm, 950mm, 1000mm

Available color: white color

Property: SiO2 >96% (>97.5%), LOI <2%, Linear Shrinkage <2%

Texsil Coated Silica Fabrics
Texsil Coated silica fabrics are the preferred choice for high temperature applications in the thermal protection of equipment and personnel. Texsil Ultra silica fabrics is the basic cloth recommended to be laminated with aluminized film or coated with silicone, PU, PTFE, graphite, vermiculite to obtain special performance properties.

The aluminized film is primarily used for its thermal reflectivity. Potential applications include: heat reflective curtains, manufacture of bellows, steel mill continuous casting inert atmosphere shroud and heat reflection in engine compartments. The silicone coated fabric is primarily used for abrasion resistance. Potential applications include: heat/abrasion harsh environments, slit tape protective wraps, insulation blanket protective covers, and special hot work protection in power plants. Both give gas and liquid impermeability.  The PU coated fabric is primarily used for abrasion resistance. The PTFE coated is primarily used for waterproof. The graphite coated is for abrasion resistance and uniform suface color after long time using in unclean sourroundings. The vermiculite coated is mainly used for additional heat protection of silica fabric for longer life. Texsil Coated silica fabrics can be fabricated with grommets and are extensively used in the Power Generation, Refinery, Construction, Shipbuilding and Metal Processing industries.

Code

Product

Thickness
(mm)

Weight
(g/m2)

Temp

(℃)

WSF030WHSR

Silicone coated Ultra Silica Fabric on two sides

0.40

450

1000

WSF040WHSR

Silicone coated Ultra Silica Fabric on two sides

0.50

550

1000

WSF060WHSR

Silicone coated Ultra Silica Fabric on two sides

0.70

800

1000

WSF100WHSR

Silicone coated Ultra Silica Fabric on two sides

1.10

1520

1000

WSF060WHSU

PU coated Ultra Silica Fabric on two sdies

0.60

660

1000

WSF060WHSA

Aluminized on Ultra Silica Fabric on one side

0.60

660

1000

WSF100 WHSA

Aluminized on Ultra Silica Fabric on one side

1.00

1200

1000

WSF075THV

Vermiculite coated Texsil Silica Fabric

0.75

620

1000

WSF130THV

Vermiculite coated Texsil Silica Fabric

1.30

1120

1000

WSF075THG

Graphite coated Texsil Silica Fabric

0.75

620

1000

WSF130THG

Graphite coated Texsil Silica Fabric

1.30

1120

1000

Customized coatings are available upon request.

Texsil Texturized Silica Fabrics
Texsil Texturized silica fabrics are plain weave structure, it's specifically designed for hot work protection applications, tadpole gasket constructions, and expansion joint constructions where 1000°C capability is required. Texsil Texturized silica fabrics are composed of texturized yarns and have improved insulating properties over the more common satin weave fabrics. Texsil Texturized silica fabrics also have improved fabrication properties for certain applications due to less edge fraying because of its weave construction and the applied hydrocarbon (H) coating. Texsil Texturized silica fabrics available in tan color and white color, extensively with stainless steel wire reinforcement are also avalable to increase the strength and abrasion.

Code

Product

Thickness
(mm)

Weight
(g/m2)

Temp

(℃)

WSF220

Texsil Silica Fabric

2.0

1400

1000

WSF230

Texsil Silica Fabric

3.0

1800

1000

WSF230S

SS insert Texsil Silica Fabric

3.0

1850

1000

Texsil Zigzag Silica Fabrics
Texsil Zigzag silica fabrics are high temperature fabrics are ideal for making textile fabricated parts for high temperature welding, industrial, and automotive applications. The broken twill weave improves handling properties over the conventional satin weave construction. Texsil Zigzag silica fabrics can be treated with a proprietary surface finish to improve handing and thermal properties. exsil Zigzag silica fabrics are typically used in the fabrication of removable insulation covers, welding curtains, drop cloths, stress relief blankets, protective screens/covers, thermal pads, furnace curtains, insulation mats and cable tray wraps.

Code

Product

Thickness
(mm)

Weight
(g/m2)

Temp

(℃)

WSF075THZ

Texsil Zigzag Silica Fabric

0.75

600

1000

WSF130THZ

Texsil Zigzag Silica Fabric

1.30

1100

1000

Available width 914mm, 1000mm, 1200mm, 1300mm
Available color: tan color and white color
Avaiable coating: Vermiculite
Property: SiO2 >96%, LOI <10%, Linear Shrinkage <10%

EV Car Fire Blankets
Ready made fire blankets for vehicles, Li-batteries, etc. to extinguish fire by isolate the air apart from fire in short time and limited area to reduce damage and win more time for fireman rescue.

Code

Product

Dimension
(m)

Weight
(kg/pc)

Temp

(℃)

SWB2x3

Silicone Ultra Silica Blanket

2x3

4.80

1000

SWB3x4

Silicone Ultra Silica Blanket

3x4

9.60

1000

SWB4x4

Silicone Ultra Silica Blanket

4x4

12.8

1000

SWB6x8

Silicone Ultra Silica Blanket

6x8

38.4

1000

SWB6x9

Silicone Ultra Silica Blanket

6x9

43.2

1000

SWB8x9

Silicone Ultra Silica Blanket

8x9

57.6

1000

SWB10x10

Silicone Ultra Silica Blanket

10x10

80.0

1000

Texsil ECO Silica Fabrics
Texsil ECO silica fabrics are high temperature fabrics used in a wide range of insulation and protection applications such as welding curtains, welding blankets and welding pads. Texsil ECO silica fabrics have a minimum silicon dioxide content of 70% and can be fabricated into many forms to withstand temperatures up to 800°C. Texsil ECO silica fabrics are available with our standard proprietary surface treatment for improved handling and fray resistance.

Code

Product

Thickness
(mm)

Weight
(g/m2)

Temp Max

(℃)

WSF075TM

Texsil ECO Silica Fabric

0.75

600

800

WSF130TM

Texsil ECO Silica Fabric

1.40

1200

800

Available width 914mm, 1000mm, 1200mm, 1300mm, 1500mm
Available color: tan color and white color
Avaiable coating: Vermiculite
Property: SiO2 >70%
